LDH43-SAI400K
43'' Wall-mounted Digital Signage
Features
>High quality panel, industrial-grade design, full metal casing.
>Dahua MPS platform provides unified remote management for system integrators and media operators.
>Strong 4 core processor provides powerful decoding capabilities, enabling premium display performance.
>Multiple installation modes satisfy a broad range of project requirements.
>Built-in media player software and USB player provide multiple methods to play contents.
Specifications
-
Model: LDH43-SAI400K
Backlight: LED
Screen Size: 43''
Aspect Ratio: 16:9
Resolution: 3840×2160
Display Colors: 1.07B(10 bits)
Brightness: 420 cd/m²
Contrast Ratio: 4000:1
Viewing Angle(H×V): 178°/178°
Display Mode: Landscape/Portrait
Response Time: 9.5ms
-
Input: RJ45 ×1, USB ×2, TF Slot ×1, HDMI ×1, Audio In×1
External Control: RJ45(LAN), USB
Wi-Fi: Optional
Speaker: 5W×2
Smart Signage Platform: Media Publish System 3.0
-
Power Supply: AC100-240V, 50/60Hz
Type: Internal
Consumption: 105W
Consumption(Standby): Less than 0.5W
Operating Temperature: 0℃~+40℃ （32℉~104℉)
Operating Humidity: 10%~85%
-
Dimensions: 956×546×69.9mm
Package: 1085x150x693mm
Bezel Width: 4.5mm
Net Weight: 18kg (44.09lb)
Gross Weight: 20kg (48.50lb)
-
Included in Box: Power cord, VESA bracket
VESA Mount: 400mm × 400mm
-
Processor:
Quad-core Cortex-A17 up to 1.6GHz
Operating System:
Android 8.1
RAM:
2GB
Storage:
16GB
Material Type:
Video, audio, image, time, weather, countdown, txt, web page, stream media, pdf
Video:
mp4,avi,mov,asf,wmv,mkv
A single file can upload up to 2G, and the resolution cannot exceed 4K
Audio:
mp3,wma,wav
A single file can upload up to 500M
Image:
jpg,jpeg,gif,bmp,png
A single file can upload up to 30M, and the resolution cannot exceed 4K
Documents:
pdf, doc, docx, ppt, pptx, xls, xlsx and txt.
A single filecan can upload up to 200 MB
Decoding Capacity:
1CH H265 4K@60/2CH H264 4K@25/2CH H265 1080P@30&2CH H264 1080P@25/4CH H265 1080P@30/2CH H264 1080P@25
